| Configuration | Console |
|---|---|
| Printing Process | 4-Drum Method |
| Control Panel | 10.1″ Smart Operation Panel |
| Color/Black & White | Color |
| Output Speed Copy/Print | 70 ppm B&W & FC (LTR) |
| First Page Out Time | 2.2 seconds B&W 3.7 seconds Color |
| Warm-Up Time | 24 seconds |
| Resolution | 600 dpi |
| System Memory | 4 GB RAM Mainframe + 4 GB RAM Panel/256 GB SSD |
| Maximum Copy Quantity | Up to 999 copies |
| Duplexing | Automatic (Standard) |
| Document Feeder Type | Single Pass Document Feeder (SPDF) |
| Single Pass Document Feeder (SPDF) | Original Capacity: 220 sheets Original Size: 2″ x 3.5″ – 11.7″ x 17″ (A6-A3, B8-B4) Paper Weight: 38 – 220 g/m2 (A6 or larger); 64 – 220g/m2 (smaller than A6) |
| Zoom Range | 25% – 400% in 1% increments |
| Supported Paper Sizes | 1st Paper Tray: 8.5″ x 11″ (A4) 2nd Paper Tray: 5.5″ x 8″ – 12″ x 18″ (A6-A3, B4-B6), Envelopes Bypass: Up to 12″ x 18″, Envelopes Custom Sizes: Width: 3.5″ – 12.6″ (90 – 320 mm), Length: 5.8″ – 49.6″ (148 – 1260 mm) |
| Supported Paper Weights | Standard Trays: 16 – 80 lb./166 lb. Index (60 – 300 g/m2) Bypass Tray: 14 – 80 lb./166 lb. Index (52 – 300 g/m2) Duplex Unit: 14 – 45lb./142 lb. Index (52 – 169 g/m2) |
| Supported Paper Types | Plain, Recycled, Special, Colored, Letterhead, Cardstock, Pre-printed, Coated, Envelope, Label, Gloss |
| Standard Paper Capacity | 1,200 sheets (2 x 550 sheets + 100-Sheet Bypass Tray) |
| Maximum Paper Capacity | 4,850 sheets (w/Tandem LCT + Side LCT) |
| Standard Output Capacity | 500 sheets 8.5″ x 11″ (A4) or smaller; 250 sheets (B4) or larger |
| Maximum Output Capacity | 3,625 sheets |
| Maximum Monthly Volume | 50000 |
| Power Source | 120V – 127V, 60Hz |
| Typical Electricity Consumption (TEC) | 0.81 kWh/week TEC value is measured based on the ENERGY STAR Ver.3.0 test method. |
| Power Consumption | Less than 1,584 W; Sleep Mode: 0.29W |
| EPEAT Status | Gold |
| Dimensions W x D x H | 23.1” x 28.5″ x 38.0″ (587 mm × 724 mm × 963 mm) |
| Weight | 233.7 lbs/106 kg |
| Processor Speed | Intel Apollo Lake 1.6 GHz |
|---|---|
| Interfaces | Standard: Ethernet 10 base-T/100 base-TX/1000 base-T, USB Host I/F Type A, USB Device I/F Type B Option: Wireless LAN (IEEE 802.11a/b/g/n/ac) |
| Network Protocol | TCP/IP (IPv4, IPv6) |
| Supported Operating Systems | Windows® 10/11/Server2012/Server2012R2/Server 2016/Server 2019/Server 2022; Mac OS X v.10.15 or later, IBM iSeries AS/400-using OS/400 Host Print Transform |
| Device Management Utilities | Web Image Monitor, @Remote |
| Printer Languages | Standard: PCL5c, PCL6, PostScript®3™ Emulation, PDF Direct Print Emulation Optional: Genuine Adobe® PostScript®3™, Adobe® PDF Direct Print |
| Font Support | Standard: PCL/PS 3 Emulation: 80 Roman fonts + 13 International fonts Optional: Genuine Adobe® PostScript®3™: 136 Roman fonts |
| Print Resolution | Up to 1200 x 1200 dpi |
| Mobile Printing Support | Apple AirPrint™, Mopria, Ricoh Smart Device Connector |
| Security Features | DataOverwriteSecurity System (DOSS) with optional HDD, SSD Encryption, User Codes, SNMP v3 Support, Encryption, Locked Print, User Authentication, 802.1x Wired Authentication, Quota Setting/Account Limit, Digitally Signed PDF, and more |
| Scan Speed (B&W & Full Color) | 150 ipm (simplex)/300 ipm (duplex) |
|---|---|
| Scanning Resolution | Up to 1200 dpi |
| Scan Area | Up to 11″ x 17″ (297 – 432 mm) |
| File Formats | Single Page: TIFF, JPEG, PDF, PDF/A, High Compression PDF, encryption PDF, OCR* Multi Page: TIFF, PDF (Default), PDF/A, High Compression PDF, encryption PDF, OCR* |
| Scan Modes | E-mail, Folder, USB, FTP |
| Footnotes | *Requires optional OCR Unit Type M52 |
| Maximum Stored Documents | 3000 |
|---|---|
| Maximum Pages/Document | 2000 |
| Maximum Page Capacity | 9000 |
| Max Number of Folders | 200 |
| Fax Standard/Optional | Optional |
|---|---|
| Type | ITU-T (CCITT) G3, maximum 3 lines |
| Circuit | PSTN, PBX |
| Fax Resolution | Standard: 8 x 3.85 line/mm, 200 x 100 dpi Optional: 16 x 15.4 line/mm, 400 x 400 dpi |
| Compression Method | MH, MR, MMR, JBIG |
| Scanning Speed | 94 spm (A4/LT LEF Image Rotation) |
| Modem Speed | 33.6 Kbps |
| Transmission Speed | 3 seconds (200 x 100 dpi, JBIG, CCITT (ITU-T) Test Chart #1, TTI off, memory transmission) |
| Memory | Standard: 4 MB (approx. 320 pages) Optional: 60 MB (approx. 4,800 pages) with optional SAF memory |
| Max Auto Dials | 2,000 Quick/Speed Dial numbers |
| Group Dials | 100 Group Dial numbers |
